Deepsea DSE701MKII

DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing
supply was at least 10 V before dropout
and supply recovers to 5 V. This is achieved
without the need for internal batteries.
MAXIMUM OPERATING CURRENT
26 mA at 12 V, 27 mA at 24 V
MAXIMUM STANDBY CURRENT
20 mA at 12 V, 21 mA at 24 V
CHARGE/FAIL EXCITATION RANGE
0 V to 35 V
OUTPUTS
START
Solid state 1.2 A negative grounding terminal
RUN
Solid state 1.2 A negative grounding terminal
PRE-HEAT
Solid state 1.2 A negative grounding terminal
GENERATOR
VOLTAGE RANGE
15 V - 333 V AC (L-N)
FREQUENCY RANGE
3.5 Hz to 75 Hz
DIMENSIONS
OVERALL
72 mm x 72 mm x 38 mm
2.8” x 2.8” x 1.5”
Excludes key switch
PANEL CUT-OUT
68 mm x 68 mm
2.7” x 2.7”
