Deesea DSE710/20

DC SUPPLY
CONTINUOUS VOLTAGE RATING
8 V to 35 V continuous
CRANKING DROPOUTS
Able to survive 0 V for 50 mS, providing
supply was at least 10 V before dropout and
supply recovers to 5 V. This is achieved
without the need for internal batteries.
MAXIMUM OPERATING CURRENT
180 mA at 12 V. 190 mA at 24 V
MAXIMUM STANDBY CURRENT
145 mA at 12 V. 150 mA at 24 V
OUTPUTS
AUXILIARY
Solid state
2.4 A DC at supply voltage
FUEL/START
Solid state
3.4 A DC at supply voltage
GENERATOR C.T.
5 A secondary 0.5 VA
GENERATOR INPUT RANGE
35 V(L-N) to 333 V AC(L-N) absolute
maximum
50 Hz - 60 Hz (min 15 V AC)
MAINS (UTILITY) SENSING INPUT
RANGE (DSE720 only)
35 V(L-N) to 333 V AC (L-N)
50 Hz - 60 Hz (min 15 V AC)
DIMENSIONS
OVERALL
209 mm x 146 mm x 30.3 mm
8.2” x 5.7” x 1.2”
PANEL CUT-OUT
182 mm x 137 mm
7.2” x 5.4”
MAXIMUM PANEL THICKNESS
8 mm
0.3”
